Product Details:
|
| Material: | Aluminum | Application: | Plastic Resin Conveying |
|---|---|---|---|
| Color: | Gray & Green | Origin: | China |
| Voltage: | 380V/50Hz/3Phase As Usual | Type: | Induction,auto Loader |
| Product Name: | Auto Loader Machine,plastic Loader,Granule Feeding Machine | Usage: | Plastic Ganules Conveying Loading Machine,plastic Loader |
| High Light: | Pellet Vacuum Auto Loader,380V Vacuum Auto Loader,Plastic Pellet Vacuum Loader |
||
OAL-S Seperate type Loader Auto Loading Machine.pd...
OAL- xxS
① ②
① Orste Auto-Loader
② Motor Power (HP)
S: Separate Type
Microprocessor for ease of use and accurate control.
Stainless hopper receiver ensures no material contamination.
Motor overload protector ensures long service life of motor.
OAL-S loaders adopts stainless steel mesh thus avoids damage to the motor.
Complete safety protection function device, like electricity indicator, phase-reversing alarm, material shortage and motor overloading alarm.
Both micro-switch hopper (OVH) and photo-sensor hopper (OPH) can be directly mounted on the feed port of molding machine.
The control device starts the vacuum motor to take out the air in the hopper, the material valve is closed meanwhile, thus negative pressure is created. With the function of negative pressure, material in the storage tank is delivered to the hopper through material pipe. The vacuum motor stops working when the suction time comes out, the material valve is opened by material, then material falls into injection machine or other equipment.
|
Model |
Motor Power |
Conveying Capacity (kg/hr) |
Motor Type |
Vertical Conveying Height (m) |
Horizontal Distance (m) |
Power |
Hopper Capacity (L) |
|
|
kw |
hp |
|||||||
|
OAL-1.5S |
1.1 |
1.5 |
200 |
Carbon Brush Type |
4 |
7.5 |
1ф, 230VAC, 50/60Hz |
7.5 |
|
OAL-1S |
0.75 |
1 |
300 |
Induction Type |
4 |
8 |
3ф, 400VAC, 50/60Hz |
7.5 |
|
OAL-2S |
1.5 |
2 |
350 |
Induction Type |
7 |
20 |
7.5 |
|
|
OAL-3S |
2.25 |
3 |
420 |
Induction Type |
9.5 |
50 |
7.5 |
|
ORSTE’s large scale Central Material Conveying System and cooling water circulation system including three major systems of centralized raw material drying, water temperature control and metering & mixing, are extensively applied in plastic injection molding industry.
The main products of the company are a series of high-tech products including Desiccant Honeycomb Dehumidifiers, Hopper Dryers, “Three-in-one” Compact Dryers, Auto / Semi-auto Weighing & Packing Machine (for plastic 25kg packages), Auto-loaders, Mold Temperature Controllers, Industrial Chillers, Mixers and Blenders, Masterbatch Dosers, Granulators, and Vibrating Screens.
With the principle of customer satisfaction first, we take contribution to society as our responsibility and constantly improve the performance of our products to timely seize the latest trend in industry, and maintain the best quality and technological edge of products.
“No Details, No Success.” The key of product quality lies in the details, we focus on details in product production and quality management. Through proactive listening, delicate service, modest attitude, ORSTE Machinery always maintains close contact with its customers.
