Product Details:
|
| Function: | Dehumdifying Drying And Loading | Application: | Plastic Connectors Production |
|---|---|---|---|
| Color: | Customized | Structure: | Compact |
| Condition: | New | Warranty: | 12 Months |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Capacity: | 75 Kg(dehumidifying Dryer) |
| High Light: | PA PEEK Dehumidifying Hopper Dryer,PEEK Dehumidifying Hopper Dryer,3 In 1 PEEK Dehumidifying Hopper Dryer |
||
OCD – xx/xxxH
① ② ③
① Orste “Three-in-one” Compact Dryer
② Hopper Capacity (L)
③ Dehumidifying Air Quantity (m3/hr)
H: Honeycomb Rotor Type
1. The OCD compact dryers can be equipped with up to four fully insulated drying bins to suit the required total throughput.
2. OCD compact dryers are the most effective way of conditioning hygroscopic plastic granules for processing and removing surface moisture.
3. The use of corrosion resistant stainless steel ensures a long lifetime and avoids contamination of the plastic granules.
4. Transparent window design for filter makes it convenient to monitor the condition of filter.
5. Material-contact surface of hopper is specially made of dust-free mirror-like stainless steel, it is suitable for the production of optical lens or food standard plastic products production.
6. High-density return air filter ensures no contamination to the material in the conveying of materials.
7. For models below OCD-160/120H, air-cooling methods is applied, which ensures low energy-saving and convenient for movement.
ORSTE “Optical” Dehumidifying Dryers provides the advantages of a consistent dew point and maximum energy efficiency. They combine the function of dehumidifying, drying and two-stage conveying into one compact machine, specified for the production of “optical class” and “food standard” products, such as lens, LGP, disposable lunch box etc. The quality desiccant honeycomb rotor provides continuous and constant low dew-point air which can be lower than -40 oC under ideal conditions.
|
Model OCD- |
20/40H |
40/40H |
80/80H |
120/80H |
160/120H |
230/120H |
300/200H |
450/200H |
600/400H |
750/400H |
|
|
Drying System |
|||||||||||
|
Hopper Capacity (kg) |
12 |
25 |
50 |
75 |
100 |
150 |
200 |
300 |
400 |
500 |
|
|
Drying Heating Power (kw) |
4 |
4 |
4 |
4 |
6 |
6 |
12 |
12 |
18 |
18 |
|
|
Drying Blower Power (kw) |
0.4 |
0.4 |
0.7 |
0.7 |
0.7 |
0.7 |
1.5 |
1.5 |
3.75 |
3.75 |
|
|
Dehumidifying System |
|||||||||||
|
Dehumidifying Air Quantity (m3/hr) |
40 |
40 |
80 |
80 |
120 |
120 |
200 |
200 |
400 |
400 |
|
|
Regenerative Heater Power (kw) |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
5.4 |
5.4 |
7.2 |
7.2 |
|
|
Regenerative Blower Power (kw) |
0.2 |
0.2 |
0.2 |
0.2 |
0.2 |
0.2 |
0.4 |
0.4 |
0.75 |
0.75 |
|
|
Feeding System |
|||||||||||
|
Feeding Blower Power(kw) |
0.75 |
0.75 |
1.1 |
1.1 |
1.1 |
1.1 |
1.5 |
1.5 |
2.2 |
2.2 |
|
|
Dia. of Material Pipe (inch) |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
|
|
Dia. of Return Air Pipe (inch) |
2 |
2 |
2 |
2 |
2.5 |
2.5 |
2.5 |
2.5 |
3 |
3 |
|
|
OMH (L) |
7.5 |
7.5 |
7.5 |
7.5 |
7.5 |
12 |
12 |
12 |
12 |
30 |
|
|
OPH (L) |
3 |
3 |
3 |
3 |
3 |
7.5 |
7.5 |
7.5 |
12 |
12 |
|
|
Dimension |
H (mm) |
1490 |
1870 |
2010 |
2100 |
2260 |
2370 |
2370 |
2410 |
2520 |
2570 |
|
W (mm) |
1000 |
1050 |
1180 |
1180 |
1340 |
1340 |
1440 |
1460 |
1645 |
1645 |
|
|
D (mm) |
730 |
730 |
780 |
780 |
810 |
810 |
940 |
940 |
1145 |
1145 |
|
|
Weight (kg) |
280 |
295 |
325 |
340 |
505 |
515 |
570 |
610 |
650 |
700 |
|
The above part is a dust collector, it is an important part for the machine if there is much dust in the plastic materials. It can remove most of the dust like substance in the plastic and greatly improve the service lifespan of the machine.
The above part is an oil removing device. If the plastic material contains some oil-like substance, the oil-like substance can go back to the honeycomb rotor which can block the holes in it. Then the drying effect and performance of the machine will be reduced a lot. So in this circumtance, the oil removing device is needed.
What is Honeycomb-rotor?
The main body of the honeycomb-rotor is a honeycomb, made by ceramic fibre and organic additives, sintered under high temperature with molecular sieve or silica gel, to be strongly bonded together and form a solid and hard surface. Not like common molecular sieve, which will produce dusts and fines to pollute raw materials when aging or become saturated requiring regular replacement, honeycomb-rotor offer unlimited long life and can be cleaned when it is polluted.
The moisture of return air is quickly absorbed by numerous tunnels before coming out of the rotor to form low dew-point air. At the same time, regenerating blower takes dry air into the honeycomb-rotor from an opposite direction to regenerate the rotor.
